Technical Specifications
| Parameter | Value |
|---|---|
| Range of Product | Modicon Premium Automation platform |
| Product Type | Non-extendable rack |
| Application | For single rack configuration |
| Number of Slots | 6 |
| Product Compatibility | TSXPSY power supply, Specific application module, TSXP57 processor, I/O module |
| Fixing Mode | 4 x M6 screws (panel mounting), or clips (35 mm symmetrical DIN rail) |
| Marking | CE |
| Dimensions (H x W x D) | 52 × 205 × 350 mm |
| Net Weight | 1.286 kg (2.83 lb) |
| Degree of Protection | IP20 |
| Pollution Degree | 2 |
| Standards | IEC 61131-2, UL 508, CSA C22.2 No 142, 73/23/EEC, 89/336/EEC, 92/31/EEC, 93/68/EEC, CSA C22.2 No 213 (Class I Div 2 Groups A, B, C, D) |
| Product Certifications | LR, RMRS, BV, ABS, GL, RINA, DNV |
| Ambient Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Ambient Storage Temperature | -25 to 70 °C (-13 to 158 °F) |
| Relative Humidity (Operation) | 10–95% non-condensing |
| Relative Humidity (Storage) | 5–95% non-condensing |
| Operating Altitude | 0 to 2000 m (0 to 6561.68 ft) |
| Protective Treatment | TC |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many modules can be installed on the TSXRKY6 rack?
A1: The TSXRKY6 supports up to 6 modules.
Q2: Is the TSXRKY6 suitable for multi-rack configurations?
A2: No, it is designed specifically for single rack configurations.
Q3: What mounting options are available for the TSXRKY6?
A3: It can be mounted using 4 M6 screws or clipped onto a 35 mm DIN rail.
Q4: Which power supply modules are compatible with TSXRKY6?
A4: It is compatible with Schneider’s TSXPSY series power supply modules.
Q5: Can TSXRKY6 be used in hazardous locations?
A5: Yes, it meets CSA C22.2 No 213 standards for Class I Division 2 Groups A, B, C, D.
Q6: What are the environmental limits for TSXRKY6?
A6: It can operate between 0–60°C and store between -25–70°C, with 10–95% RH during operation.
Q7: What certifications does the TSXRKY6 carry?
A7: It is certified by LR, DNV, ABS, BV, GL, RINA, and RMRS.
Q8: What is the level of protection provided by the rack enclosure?
A8: The TSXRKY6 offers IP20 protection.
