Technical Specifications
| Parameter | Description |
|---|---|
| Range of Product | Modicon Premium Automation Platform |
| Product Type | AS-Interface Master Module |
| Range Compatibility | AS-Interface Cabling System |
| AS-Interface Profile | M2 |
| AS-i Version | V1 |
| Addressing | Standard |
| Number of Server Devices | 31 (Standard Addressing) |
| Type of Connectable Interfaces | Discrete I/Os (4 Inputs / 4 Outputs) |
| Electrical Connection | Terminal Block for AS-Interface Line |
| Supply | Via power supply integrated into the host platform |
| Certifications | AS-Interface Certificate No. 12001 |
| Standards Complied | IEC 60068-2-6 (Fc), IEC 60068-2-27 (Ea), IEC 61131-2 |
| Operating Temperature | 32 to 140 °F (0 to 60 °C) |
| Storage Temperature | -13 to 158 °F (-25 to 70 °C) |
| Degree of Protection (IP Rating) | IP20 |
| Dimensions (W × H × D) | 55 × 57 × 255 mm |
| Weight | 0.324 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of network is the TSXSAZ10 module used for?
A1: It is used for AS-Interface (Actuator Sensor Interface) networks, version V1 with M2 profile.
Q2: How many devices can the TSXSAZ10 support?
A2: The module supports up to 31 standard-address AS-i devices.
Q3: How does the module receive its power supply?
A3: It is powered via the host platform’s integrated power supply.
Q4: What type of I/O can be connected to this module?
A4: The module supports discrete I/Os – 4 inputs and 4 outputs.
Q5: What kind of electrical connection does it use?
A5: It uses a terminal block connection for the AS-Interface line.
Q6: Is the module compliant with any industrial standards?
A6: Yes, it complies with IEC 60068-2-6 (Fc), IEC 60068-2-27 (Ea), and IEC 61131-2 standards.
Q7: What is the module’s protection class?
A7: The TSXSAZ10 has an IP20 protection rating.
Q8: What is the storage temperature range of the module?
A8: It can be stored in temperatures from -25 to 70 °C (-13 to 158 °F).
