Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 3502E |
| Module Type | TMR (Triple Modular Redundant) Digital Input Module |
| Input Type | 48 VAC/VDC, commoned in groups of 8 |
| Number of Input Points | 32 |
| Input Circuit Isolation | Channel-to-channel isolation |
| Self-Test Capability | Yes – detects stuck-ON conditions |
| Module Redundancy | Supports hot-spare configuration |
| Input Signal Detection | Opto-isolated per point |
| Compatible Termination | External Termination Panels or fanned-out cables |
| Dimensions (W x H x D) | 129.5 x 75 x 114.5 mm |
| Weight | 0.5 kg |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 75°C |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 2G @ 10–150 Hz per IEC 60068-2-6 |
| Shock Resistance | 15G for 6–11 ms per IEC 60068-2-27 |
| EMC Compliance | IEC 61000 series, CISPR 16/11 |
FAQ
FAQ
Q1: What is the input voltage specification for the 3502E module?
A1: The 3502E module supports 48 VAC/VDC nominal input grouped in blocks of 8.
Q2: How many input channels are available on the 3502E module?
A2: It provides 32 discrete input channels.
Q3: Does the 3502E support self-test diagnostics?
A3: Yes, it includes built-in diagnostics to detect stuck-ON input conditions.
Q4: Is channel-to-channel isolation available in the 3502E module?
A4: Yes, the 3502E has complete isolation between channels A, B, and C.
Q5: Can the 3502E module be used with hot-spare redundancy?
A5: Yes, it supports installation with a hot-spare module for high availability.
Q6: What kind of input signal detection does it use?
A6: The module uses opto-isolated detection for each input point.
Q7: What is the physical size and weight of the module?
A7: The dimensions are 129.5 x 75 x 114.5 mm, and the weight is 0.5 kg.
Q8: What is the operating temperature range for the 3502E?
A8: The module operates in environments from 0°C to 60°C.
