Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAI143-S50 |
| Type | Analog Input Module (Isolated) |
| Number of Input Channels | 16 channels |
| Input Signal | 4 to 20 mA DC |
| Input Resistance (Power ON) | 270 Ω (at 20 mA) to 350 Ω (at 4 mA) |
| Input Resistance (Power OFF) | 500 kΩ or more |
| Allowable Input Current | Max. 24 mA |
| Withstanding Voltage | 1500 V AC, 1 minute (between input and system) |
| Accuracy | ±16 µA |
| Data Update Period | 10 ms |
| Step Response Time | 100 ms |
| Temperature Drift | ±16 µA / 10 °C |
| Transmitter Power Supply | 19.0 V or higher (at 20 mA), 25.5 V max (at 0 mA), 25 mA limit |
| Input Mode Configuration | Configurable per channel via setting pin |
| External Connections | Pressure clamp terminal, MIL connector, KS1 cable |
| HART Communication | Supported |
| Maximum Power Consumption | 230 mA (5 V DC), 540 mA (24 V DC) |
| Dimensions (W × D × H) | 107.5 × 32.8 × 130 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of signal does the AAI143-S50 support?
A1: It supports 4 to 20 mA DC analog current signals.
Q2: Is the AAI143-S50 input isolated?
A2: Yes, it provides isolated input channels for each signal.
Q3: How many channels does the AAI143-S50 offer?
A3: It offers 16 analog input channels.
Q4: Can this module provide transmitter power?
A4: Yes, it can supply 19.0 V to 25.5 V with a current limit of 25 mA.
Q5: Does the AAI143-S50 support HART communication?
A5: Yes, HART communication is supported when used with compatible bus units.
Q6: What is the accuracy of this module?
A6: The accuracy is ±16 microamperes.
Q7: What are the dimensions and weight of the module?
A7: Dimensions are 107.5 × 32.8 × 130 mm and the weight is 0.3 kg.
Q8: Is it suitable for use in redundant configurations?
A8: Yes, it supports dual-redundant configurations for high reliability.
