Technical Specifications
| Parameter | Description |
|---|---|
| Model | AAM21-S2 |
| Input Types | mV, Thermocouple (TC), RTD |
| Number of Input Channels | 16 channels |
| Thermocouple Types Supported | Type B, E, J, K, N, R, S, T |
| RTD Types Supported | PT100, JPt100 |
| Measurement Ranges | mV: -10 to +100 mV (typical), TC: According to thermocouple type |
| Conversion Resolution | 16 bits |
| Input Isolation | Channel-to-channel isolation not provided; isolated from system |
| Accuracy | ±0.1% of full scale (varies by sensor and range) |
| Cold Junction Compensation | Internal CJC available |
| Input Impedance | >10 MΩ (for mV and TC inputs) |
| Input Connection Method | Screw terminals |
| Module Installation | Mounted on AMN11 analog I/O nest |
| I/O Nest Compatibility | AMN11, AMN12 |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 70°C |
| Relative Humidity | 5 to 95% RH (non-condensing) |
| Power Consumption | Approx. 2.5 W |
| Dimensions (W × H × D) | 42.9 × 130 × 146.8 mm |
| Weight | 0.10 kg |
| Conformance Standards | IEC 584 (for TC), IEC 751 (for RTD) |
| Mounting Orientation | Vertical installation recommended |
| Diagnostic Function | Input disconnection detection, IOP (input open) detection |
FAQ
Frequently Asked Questions (FAQ)
Q1: What types of sensors can be connected to the AAM21-S2 module?
A1: The AAM21-S2 supports mV signals, thermocouples (types B, E, J, K, N, R, S, T), and RTDs (PT100, JPt100).
Q2: Does the module offer cold junction compensation for thermocouples?
A2: Yes, it is equipped with internal cold junction compensation (CJC) functionality.
Q3: Is channel-to-channel isolation available in AAM21-S2?
A3: No, channels are not isolated from each other. The module is isolated from the system side.
Q4: What is the resolution of analog input conversion?
A4: The analog-to-digital conversion resolution is 16 bits.
Q5: Which I/O nests are compatible with this module?
A5: The AAM21-S2 is compatible with AMN11 and AMN12 I/O nests.
Q6: What is the purpose of the IOP detection function?
A6: The IOP (input open) detection function monitors for open circuit conditions on each input channel.
Q7: Can this module be installed in any orientation?
A7: Vertical mounting is recommended to ensure proper thermal dissipation and reliability.
Q8: What is the physical size and weight of the AAM21-S2 module?
A8: The dimensions are 42.9 × 130 × 146.8 mm, and the weight is 0.10 kg.
