Technical Specifications
| Parameter | Value |
|---|---|
| Model | AAP849-S00 |
| Number of I/O channels | 8-channel input / 8-channel output, non-isolated |
| Input signal | Transistor contact (open collector) |
| Output signal | 4 to 20 mA |
| Input frequency | 0 to 12 kHz |
| Pulse detection edge | Trailing edge |
| Allowable load resistance | 0 to 750 Ω |
| Circuit-open detection | Less than 0.65 mA |
| Accuracy | ±48 µA |
| Data update period | 1 ms / 10 ms |
| Output step response time | 40 ms |
| Temperature drift | ±16 µA/10 °C |
| Maximum current consumption | 310 mA (5 V DC), 250 mA (24 V DC) |
| Weight | 0.3 kg |
| Dimensions | 130 × 32.8 × 127.2 mm |
| External connection | Dedicated cable (KS1) |
FAQ
FAQs
Q1: What is the input frequency range for the AAP849-S00 module?
A1: The input frequency range for the AAP849-S00 Pulse Input Module is 0 to 12 kHz.
Q2: What type of output does the AAP849-S00 module provide?
A2: The module provides a 4 to 20 mA output.
Q3: Can this module detect open circuits?
A3: Yes, the module can detect open circuits with a current detection of less than 0.65 mA.
Q4: What is the accuracy of the AAP849-S00 Pulse Input Module?
A4: The accuracy of the module is ±48 µA.
Q5: How many channels of I/O does the AAP849-S00 module support?
A5: The module supports 8 channels of input and 8 channels of output.
Q6: What is the maximum current consumption of the module?
A6: The maximum current consumption is 310 mA when powered by 5 V DC, or 250 mA when powered by 24 V DC.
Q7: How much does the AAP849-S00 module weigh?
A7: The module weighs 0.3 kg.
Q8: What type of external connections can be used with the AAP849-S00 module?
A8: The module can be connected using a dedicated cable (KS1).
