Technical Specifications
| Parameter | Description |
|---|---|
| Model | ADV142-P12 |
| Number of Input Channels | 16 channels |
| Rated Input Voltage | 200 to 240 V AC, 50/60 Hz |
| Input ON Voltage (Peak) | 160 V AC (226 V) to 264 V AC (373 V) |
| Input OFF Voltage (Peak) | 40 V AC (56 V) or less |
| Typical Input Current | 6.2 mA / channel (@240 V/60 Hz) |
| Maximum Input Current | 9.3 mA / channel |
| Withstanding Voltage | 2 kV AC (between input and system) for 1 min |
| Common Withstand Voltage | 1.35 kV AC (common every 8 channels) for 1 min |
| Input Response Time | ≤160 ms (status input) |
| Min. ON Detection Time | 200 ms (for pushbutton input) |
| Max. ON/OFF Cycle | 2.5 Hz (for pushbutton input) |
| Max. Current Consumption | 500 mA (5 V DC) |
| External Connection | Pressure clamp terminal, Dedicated cable AKB333 |
| Dimensions (W×H×D) | 107.5 × 130 × 32.8 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What input voltage does the ADV142-P12 support?
A1: It supports 200 to 240 V AC input at 50/60 Hz.
Q2: What is the maximum input current per channel?
A2: The maximum input current is 9.3 mA per channel.
Q3: Is ADV142-P12 suitable for redundant configuration?
A3: Yes, ADV142 can be used in a dual-redundant setup.
Q4: What is the input response time of this module?
A4: The input response time is 160 milliseconds or less.
Q5: What external connection method does it use?
A5: It uses pressure clamp terminals and a dedicated cable (AKB333).
Q6: What is the minimum ON detection time?
A6: The minimum ON detection time for pushbutton input is 200 milliseconds.
Q7: Does the module support pushbutton input?
A7: Yes, it includes a function for detecting pushbutton edge input.
Q8: What are the physical dimensions of the module?
A8: The dimensions are 107.5 × 130 × 32.8 mm, and it weighs 0.3 kg.
