Technical Specifications
| Parameter | Description |
|---|---|
| Model | ADV159-P00 |
| Number of Input Channels | 32 channels |
| Input Type | Contact or voltage signal input |
| Contact Input Signal | OFF: 100 kΩ or more; ON: 200 Ω or less |
| Min Current (shorted) | 1.25 mA |
| Voltage Input Signal | OFF: 4.5 to 25 V DC; ON: ±1 V DC, 200 Ω or less |
| Pushbutton Input Support | Supported |
| Status Input Response | ≤ 8 ms |
| Min ON Detection Time | 20 ms (for pushbutton input) |
| Max ON/OFF Frequency | 25 Hz (for pushbutton input) |
| Channel Isolation | Isolated per channel |
| Max Current Consumption | 330 mA (5 V DC) |
| External Connection | Dedicated cable (KS2) |
| Compatible Card | ST3 compatible |
| Dimensions (W×H×D) | 127.2 × 130 × 32.8 mm |
| Weight | 0.4 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Does the ADV159-P00 provide channel isolation?
A1: Yes, all 32 input channels are isolated to ensure safe and reliable signal separation.
Q2: Is pushbutton input supported on this module?
A2: Yes, the ADV159-P00 supports pushbutton input and can detect edge changes.
Q3: What is the input response time of the module?
A3: The status input response time is less than or equal to 8 ms. Pushbutton inputs require a minimum ON time of 20 ms.
Q4: Does the module support voltage input signals?
A4: Yes, it accepts OFF signals between 4.5 and 25 V DC, and ON signals at ±1 V DC (with impedance ≤200 Ω).
Q5: What are the physical dimensions of the ADV159-P00?
A5: The module measures 127.2 × 130 × 32.8 mm, suitable for compact system integration.
Q6: What is the module’s maximum current consumption?
A6: The maximum current consumption is 330 mA at 5 V DC.
Q7: What type of external connection is used?
A7: It uses a dedicated KS2 cable for secure and efficient signal connection.
Q8: What system type is the ADV159-P00 compatible with?
A8: It is compatible with ST3 type systems within the Yokogawa control architecture.
