Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ADV169-P00 |
| Type | Digital Input Module |
| Number of Input Channels | 64 channels |
| Signal Isolation | Common every 16 channels |
| Input Signal (Contact Input) | OFF: ≥100 kΩ, ON: ≤200 Ω |
| Input Signal (Voltage Input) | OFF: 4.5–25 VDC, ON: ±1 VDC (≤200 Ω) |
| Minimum Contact Current | 1.25 mA |
| Input Contact Rating | 5 VDC, ≥20 mA |
| Pushbutton Input Function | Not supported |
| Input Response Time | ≤8 ms (status input) |
| Maximum Current Consumption | 800 mA (5 VDC) |
| Compatible Card | ST6 |
| External Connection | Dedicated cable (KS9) |
| Dimensions (W x H x D) | 130 x 127.2 x 32.8 mm |
| Weight | Approx. 0.3 kg |
FAQ
FAQs
Q1: What type of signals does the ADV169-P00 accept?
A1: It accepts contact or voltage input signals. Contact ON resistance must be 200 Ω or less, OFF must be 100 kΩ or more.
Q2: How many input channels are supported?
A2: The module supports 64 digital input channels.
Q3: Is there isolation between input channels?
A3: Input channels are grouped with common isolation for every 16 channels.
Q4: What is the input response time?
A4: The input response time is 8 milliseconds or less.
Q5: Can this module detect pushbutton input or SOE (Sequence of Events)?
A5: No, ADV169-P00 does not support pushbutton or SOE input functions.
Q6: What cable is required for external connection?
A6: A KS9 dedicated cable is used for external connections.
Q7: What is the power consumption of the module?
A7: Maximum current consumption is 800 mA at 5 VDC.
Q8: What is the size and weight of the ADV169-P00?
A8: The module measures 130 x 127.2 x 32.8 mm and weighs approximately 0.3 kg.
