Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | AFV10D-S41401 |
| Product Type | Duplexed Field Control Unit |
| Installation | 19-inch rack mountable |
| Communication | Vnet/IP with redundant communication support |
| Control Function | LFS1500 control function, expandable with LFS1550 |
| Max Node Support | Up to 14 ESB and ER bus nodes |
| ESB Bus Speed | 128 Mbps, max 10 m (with YCB301 cable) |
| ER Bus Speed | 10 Mbps, max 185 m (with YCB141 coaxial cable) |
| Network Topology | Bus topology |
| Redundancy | Dual CPU, dual communication module support |
| Power Supply | 24 VDC or 100–240 VAC |
| Dimensions (W×H×D) | 207 × 265.9 × 482.6 mm |
| Weight | 8 kg |
| Operating Temperature | 0 – 50°C |
| Operating Humidity | 10 – 90% RH, non-condensing |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the AFV10D-S41401 device used for?
A1: It is a duplexed field control unit used in industrial automation systems for control and I/O communication.
Q2: Which communication buses are supported by AFV10D-S41401?
A2: It supports both ESB and ER buses, with redundant communication capability.
Q3: How many I/O nodes can be connected?
A3: Up to 14 nodes (ESB and ER combined) when used with LFS1550 Node Expansion Package.
Q4: Is the control function expandable?
A4: Yes, via the LFS1500 control function and LFS1550 node expansion package.
Q5: What are the typical application industries?
A5: Petrochemical, power, pharmaceutical, food & beverage, water treatment, and other industrial sectors.
Q6: Does it support redundancy?
A6: Yes, it supports dual CPU, dual communication channels, and redundant power supply.
Q7: What is the maximum communication distance?
A7: Up to 185 meters for ER bus (YCB141) and 10 meters for ESB bus.
Q8: How is compliance with industrial standards ensured?
A8: The AFV10D complies with multiple safety and EMC standards including CSA, CE, and KC.
