Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | AIP121-S2 |
| Module Type | Analog Input Module |
| Number of Channels | 16 channels |
| Input Signal Type | 4–20 mA Current, HART compatible |
| Input Impedance | Approx. 250 Ω |
| Data Resolution | 16-bit |
| Accuracy | ±0.1% of reading ±1 LSB |
| Channel Isolation | No isolation between channels; opto-isolated from system |
| Power Supply Voltage | 24 VDC (supplied by system) |
| Power Consumption | Typically 4.0 W |
| Operating Temperature | 0 to 55°C |
| Storage Temperature | -20 to 70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Redundancy Support | Yes, supported for redundant configurations |
| Mounting Method | Mounted on standard FCS base |
| Dimensions | 150 x 90 x 70 mm |
| Weight | 2.5 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of input signal does the AIP121-S2 support?
A1: It supports 4–20 mA current input and is HART protocol compatible.
Q2: Does the module provide channel-to-channel isolation?
A2: No, channel-to-channel isolation is not provided, but channel-to-system isolation is opto-isolated.
Q3: Is HART communication supported on all input channels?
A3: Yes, HART communication is supported on all 16 channels.
Q4: What is the data accuracy of the AIP121-S2?
A4: The accuracy is ±0.1% of the reading plus ±1 LSB.
Q5: What are the temperature specifications for this module?
A5: Operating temperature is 0 to 55°C; storage temperature is -20 to 70°C.
Q6: How is the module mounted?
A6: It is mounted on a standard FCS base used in Yokogawa control systems.
Q7: Does the AIP121-S2 support redundancy?
A7: Yes, it supports redundant system configurations.
Q8: What are the module’s dimensions and weight?
A8: Dimensions are 150 x 90 x 70 mm, and it weighs 2.5 kg.
