Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | AIP423-S1 |
| Product Type | Hard Disk Module |
| Application | CENTUM CS 3000 Field Control Station (FCS) |
| Interface | IDE (ATA) or SCSI (depends on variant) |
| Compatible Slot | FCU Backplane Slot |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 60°C |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Dimensions | 76 × 254 × 279 mm |
| Weight | 1.0 kg |
| Mounting | Installed in system cabinet |
| Environmental Class | JEIDA-29 S1 |
FAQ
FAQ
Q1: What is the function of the AIP423-S1 module?
A1: It serves as the hard disk storage device for the CENTUM CS 3000 Field Control Station, storing system data and logs.
Q2: Can AIP423-S1 be hot-swapped?
A2: No, the module must be replaced with power off to prevent data corruption or hardware damage.
Q3: What is the recommended replacement cycle for the AIP423-S1?
A3: The hard disk module is typically replaced every 5 to 8 years depending on usage and environmental conditions.
Q4: Is the AIP423-S1 compatible with all FCUs?
A4: It is compatible with FCUs designed for CENTUM CS 3000, but specific system firmware requirements may apply.
Q5: How do I verify if the AIP423-S1 is functioning correctly?
A5: Status can be monitored via the ICS software or the front panel LED indicators.
Q6: What should be done if the hard disk fails?
A6: Power down the system and replace the AIP423-S1 with a new certified module, then restore the system image.
Q7: What is the data interface used by AIP423-S1?
A7: It typically uses an IDE or SCSI interface, depending on production series.
Q8: Can I use a commercial off-the-shelf HDD instead?
A8: No, the AIP423-S1 includes Yokogawa-specific firmware and interface; only certified replacements should be used.
