Technical Specifications
| Item | Specification |
|---|---|
| Model | AIP830-001 Operation Keyboard for Single-loop Operation |
| Type | Flat keyboard with built-in USB speaker (sound function) |
| Interface | USB A Type × 2 |
| USB Standard | Keyboard: USB 2.0 (Full-speed, Bus-powered) Speaker: USB 1.1 (Bus-powered) |
| Input Voltage | 5 V ±5% (supplied via USB from PC) |
| Max Current Consumption | 1 A |
| Ambient Operating Temperature | 5 to 40°C |
| Storage/Transport Temperature | -20 to 60°C |
| Humidity | 20 to 80% RH (non-condensing) |
| Weight | Approx. 2.5 kg (with VESA bracket) |
| Dimensions (W x D x H) | 500 × 225 × 50 mm |
| Color | Black (Equivalent to Munsell No. N1.5) |
| Compliance | IEC 61010-1 Installation Category Class I |
FAQ
FAQ
Q1: What type of interface does the AIP830-001 use?
A1: It uses two USB Type-A connectors—one for keyboard function (USB 2.0) and one for sound (USB 1.1).
Q2: Does the AIP830-001 support VESA mounting?
A2: Yes, models with the /VESA option include a bracket for VESA-compatible mounting.
Q3: What are the dimensions and weight of the AIP830-001?
A3: The dimensions are 500 mm × 225 mm × 50 mm, and it weighs approximately 2.5 kg with the VESA bracket.
Q4: Is an external power supply needed for the keyboard?
A4: No, the keyboard is bus-powered through the USB port of the PC.
Q5: Can the operation keys be customized?
A5: Yes, the unit includes 64 user-definable function keys for plant operation and control.
Q6: What is the operating temperature range?
A6: The operating range is 5 to 40°C, with a storage range of -20 to 60°C.
Q7: Are there different configurations available for confirmation keys?
A7: Yes, there are two types: Type A and Type B, selectable via suffix codes.
Q8: Is the AIP830-001 compliant with international safety and EMC standards?
A8: Yes, it complies with standards such as CSA, CE, RCM, KC, EAC, and Morocco Cم Marking, depending on the host PC.
