Technical Specifications
| Item | Specification |
|---|---|
| Model | AIP830-111 Operation Keyboard for Single-loop Operation |
| Keyboard Type | Flat keyboard with built-in USB speaker |
| PC Interface | USB A type ×2 (Operation: USB 2.0 / Sound: USB 1.1, Full-speed, Bus-powered) |
| Input Voltage | 5 V ±5% (supplied from PC USB port) |
| Maximum Current Consumption | 1 A |
| Ambient Temperature (Use) | 5 to 40°C |
| Ambient Temperature (Storage) | -20 to 60°C |
| Ambient Humidity | 20% to 80% RH (non-condensing) |
| Weight | Approx. 2.5 kg (with VESA bracket) |
| Dimensions | 500 × 225 × 50 mm |
| Color | Black (equivalent to Munsell No. N1.5) |
| Installation Category | IEC 61010-1 Class I |
| Function Keys | 64 user-definable keys |
| Compliance Standards | CSA, CE, EAC, KC, RCM, Cم (when host PC is compliant) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of interface does the AIP830-111 use to connect with a PC?
A1: It uses two USB Type-A connectors — one for operation (USB 2.0) and one for sound (USB 1.1).
Q2: Is an external power supply needed?
A2: No, the unit is powered directly through the USB connection from the host PC.
Q3: What is the total power consumption of the unit?
A3: The maximum current draw is 1 A from the USB port.
Q4: Can the keyboard be used in harsh environments?
A4: The operating temperature range is 5°C to 40°C, and storage from -20°C to 60°C. It is not rated for extreme industrial environments.
Q5: What is the weight of the keyboard including the VESA bracket?
A5: Approximately 2.5 kg.
Q6: What is the purpose of the 64 function keys?
A6: These are user-definable keys used for process control and plant monitoring functions.
Q7: Is there built-in audio support?
A7: Yes, the keyboard includes a USB speaker and an electronic buzzer for alarms.
Q8: Does the AIP830-111 comply with CE and CSA standards?
A8: Yes, but only if the host PC to which it is connected is also compliant and bears the respective marks.
