Technical Specifications
| Parameter Item | Details |
|---|---|
| Model Number | ALP111-S00 |
| Interface Type | PROFIBUS-DP |
| Communication Method | EIA-RS-485 compliant |
| Signal Isolation | Isolated |
| Transmission Speed | 9600 bps to 12 Mbps |
| Max Transmission Distance | 1.2 km per segment (at 9600 bps) |
| Communication Port | 1 port (D-sub 9 pin, female) |
| Maintenance Port | D-sub 9 pin (male), RS-232C interface |
| Max Current Consumption | 0.7 A |
| Communication I/O Capacity | 1000 words per module |
| Number of Definitions | Up to 200 per module |
| Dimensions | 130 × 129.5 × 32.8 mm |
| Weight | 0.3 kg |
| Installation Support | AFV10/30/40, AFF50, AFG Series, ANB/ANR Nodes |
| Redundancy Support | Supported via adjacent slot pairing |
| Configuration Software | SyCon-PB/YOKO |
FAQ
Frequently Asked Questions (FAQ)
Q1: Which control station models are compatible with ALP111-S00?
A1: It is compatible with AFV10, AFV30, AFV40, AFF50, and the AFG series stations.
Q2: Does the module support redundancy?
A2: Yes, redundancy is supported by installing two ALP111 modules in adjacent slots.
Q3: How many PROFIBUS slave devices can it connect?
A3: Up to 31 devices without repeaters, and up to 125 devices with repeaters.
Q4: What is the transmission speed range of the module?
A4: It supports speeds ranging from 9600 bps to 12 Mbps.
Q5: What are the physical dimensions of the module?
A5: The module measures 130 x 129.5 x 32.8 mm.
Q6: What configuration software is supported?
A6: Supported configuration tool is SyCon-PB/YOKO from Hilscher.
Q7: What ports are provided on the module?
A7: One PROFIBUS-DP port (female) and one RS-232C maintenance port (male).
Q8: What is the maximum communication data capacity per module?
A8: Each ALP111 module supports up to 1000 words of communication data.
