Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ANB10D-410/NDEL |
| Power Supply | 100-120 V AC, 220-240 V AC, 24 V DC |
| Power Consumption | 100-120 V AC: 200 VA, 120 W |
| 220-240 V AC: 230 VA, 120 W | |
| 24 V DC: 5.5 A | |
| Weight | 10 kg (including 8 I/O modules) |
| Dimensions | 482.6 × 221.5 × 205 mm |
| Mounting | 19-inch rack mounting |
| Module Configuration | Up to 8 I/O modules |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the ANB10D-410/NDEL?
A1: The ANB10D-410/NDEL is a dual-redundant ESB bus node unit that facilitates communication between field I/O signals and the Field Control Unit (FCU). It also supplies power to the I/O modules.
Q2: How is the ANB10D-410/NDEL node unit installed?
A2: The ANB10D-410/NDEL should be installed in a 19-inch rack, secured with M5 screws, and requires an insulating pad (accessory) for safe installation.
Q3: What are the power supply options for this device?
A3: The device supports three power supply options: 100-120 V AC, 220-240 V AC, or 24 V DC.
Q4: How many ANB10D node units can be connected to each FCU?
A4: Up to 8 ANB10D node units can be connected to each FCU.
Q5: What is the power consumption of the ANB10D-410/NDEL?
A5: The power consumption is 200 VA, 120 W for 100-120 V AC, 230 VA, 120 W for 220-240 V AC, and 5.5 A for 24 V DC.
Q6: What is the weight of the device?
A6: The device weighs approximately 10 kg, including 8 I/O modules.
Q7: What environmental conditions is the ANB10D-410/NDEL suitable for?
A7: The ANB10D-410/NDEL is designed for industrial environments, with a temperature range of -20°C to 70°C, and offers an explosion protection option.
Q8: How can the safe installation of the ANB10D be ensured?
A8: Safe installation requires using the correct installation accessories, including insulating partitions and explosion protection options to meet safety standards.
