Technical Specifications
| Parameter | Specification |
|---|---|
| Model | CP451-11 |
| Product Type | Processor Module for FIO System |
| Communication Network | Dual-redundant Vnet/IP |
| Bus Type | ESB Bus, Optical ESB Bus, ER Bus |
| Installation | Rack-mountable, node-mounted |
| Redundancy Support | Supported (Duplex Configuration Available) |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 60°C |
| Relative Humidity | 5 to 95% RH (non-condensing) |
| Vibration Resistance | 2.0 m/s² (14 to 100 Hz), 0.25 mm (1 to 14 Hz) |
| Shock Resistance | Horizontal 49.0 m/s², Vertical 98.0 m/s² (during transport) |
| Noise Immunity | Electric field: ≤3 V/m, Magnetic field: ≤400 A/m |
| Static Discharge Protection | Contact: 4 kV, Air: 8 kV |
| Altitude | ≤2000 m |
| Dimensions (W x H x D) | 66 x 49 x 125 mm |
| Weight | 0.45 kg |
FAQ
FAQ
Q1: What is the primary function of the CP451-11 module?
A1: It serves as a processor module in the Yokogawa FIO system, managing control logic and communication over Vnet/IP.
Q2: Is the CP451-11 module capable of operating in a redundant configuration?
A2: Yes, it supports duplex configurations for enhanced reliability and system availability.
Q3: Which communication protocols are supported by CP451-11?
A3: It supports dual-redundant Vnet/IP communication for high-reliability network operation.
Q4: What environmental conditions can the CP451-11 withstand during operation?
A4: It operates reliably at 0 to 50°C and 5–95% RH without condensation.
Q5: What types of node buses can the CP451-11 connect to?
A5: It supports ESB Bus, Optical ESB Bus, and ER Bus connections.
Q6: What certifications or standards does the CP451-11 comply with?
A6: It complies with CSA, CE, EAC, RCM, and KC standards for safety and EMC.
Q7: What installation method is used for CP451-11?
A7: It is designed for rack-mount installation in a node unit.
Q8: Is the CP451-11 suitable for use in high-vibration environments?
A8: Yes, it is compliant with industrial vibration resistance standards up to 2.0 m/s².
