Technical Specifications
| Item | Description |
|---|---|
| Model | CP461-10 |
| Application | Used in AFV30 series Field Control Units |
| Mounting Style | Rack-mounted in 19-inch chassis |
| Configuration | Supports dual-redundant configuration (2 identical modules) |
| Communication Interface | Vnet/IP, dual-redundant |
| Max. Node Units | Up to 13 per FCU (includes ESB and optical ESB bus) |
| READY Contact Output | 2 terminals (NC, C), opens during FCU failure |
| Battery Backup Duration | Up to 72 hours for main memory |
| Battery Recharge Time | Minimum 48 hours |
| Dimensions (W × H × D) | 32.8 × 149 × 199.5 mm |
| Weight | 0.7 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Which control units is the CP461-10 compatible with?
A1: The CP461-10 is designed for use in CENTUM VP AFV30 series Field Control Units.
Q2: Can CP461 be replaced with CP471 by the user?
A2: No, replacement must be carried out by a Yokogawa authorized service engineer.
Q3: Does the CP461 module support redundant operation?
A3: Yes, redundant configuration is possible using two identical CP461 modules.
Q4: What type of communication interface does the CP461 use?
A4: It uses dual-redundant Vnet/IP communication.
Q5: Will memory data be lost during power failure?
A5: No, the CP461 has battery backup to retain main memory data for up to 72 hours.
Q6: How many node units can a single FCU connect?
A6: Up to 13 ESB or optical ESB bus node units per FCU.
Q7: How is the CP461 installed?
A7: It is installed into a 19-inch rack using M5 screws.
Q8: What is the weight of the CP461 module?
A8: The weight is approximately 0.7 kg.
