Technical Specifications
| Parameter | Specification |
|---|---|
| Model | CP461-50-S2 |
| Function | Processor Module for Field Control Unit |
| Mounting | 19-inch Rack Mountable |
| Configuration | Dual-redundant supported |
| Compatible Units | AFV30S / AFV30D |
| Number of I/O Modules | Max. 8 |
| Communication Interface | Dual-redundant Vnet/IP |
| Memory Backup | Battery-backed (Max. 72 hours) |
| Battery Recharge Time | Min. 48 hours |
| READY Contact Output | 2 terminals (NC, C) |
| Contact Rating | 30 V DC, Max. 0.3 A |
| External Interface | ESB/Optical ESB Bus via EC401/EC402 |
| Operating Voltage (with FCU) | 100–120 V AC / 220–240 V AC / 24 V DC |
| Power Consumption (FCU total) | 200 VA (100–120 V), 230 VA (220–240 V), 5.5 A (24 V DC) |
| Dimensions | 32.8 mm x 149 mm x 199.5 mm |
| Weight | 0.7 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the CP461-50-S2 module?
A1: It serves as the central processing unit in the Yokogawa Field Control Unit (FCU), executing control logic and managing communication.
Q2: Does the CP461-50-S2 support dual redundancy?
A2: Yes, it supports dual-redundant configuration when paired with an identical module.
Q3: What communication protocol is used?
A3: It uses a dual-redundant Vnet/IP protocol for reliable data exchange.
Q4: How many I/O modules can be connected?
A4: A maximum of 8 I/O modules can be connected to the FCU system with CP461.
Q5: What happens during power failure?
A5: The module retains memory using battery backup for up to 72 hours.
Q6: What is the contact output rating of the READY signal?
A6: 30 V DC with a maximum current of 0.3 A.
Q7: Can CP461-50-S2 be used in marine environments?
A7: Yes, if the “/MRN” option is specified, the unit complies with marine standards.
Q8: What type of maintenance does CP461-50-S2 typically require?
A8: The module requires periodic battery checks and replacement after prolonged use to ensure memory backup reliability. Firmware updates and diagnostic monitoring are recommended under planned maintenance schedules.
