Technical Specifications
| Item | Specification |
|---|---|
| Model | CP471-51 |
| Type | Processor Module (for AFV30, AFV40, A2FV50, A2FV70) |
| Operating System | Requires CENTUM VP R6.05 or later |
| Redundancy | Supports dual-redundant configuration |
| Dimensions | 199.5 x 149 x 32.8 mm |
| Weight | 0.7 kg |
| Compatible Bus | ESB bus coupler module (EC401, style code S3 or later) |
| Installation | For use in CENTUM field control units only |
| Explosion Proof | -0: No explosion protection; -1: With explosion protection |
| Standard Accessory | Processor Module Modification History Label (T9044AR) |
FAQ
Frequently Asked Questions (FAQ)
Q1: Which field control units are compatible with CP471-51?
A1: CP471-51 is compatible with CENTUM field control units including AFV30, AFV40, A2FV50, and A2FV70 series.
Q2: Does the CP471-51 support hot-swapping?
A2: In dual-redundant configuration, CP471-51 can be replaced online by the user without system shutdown.
Q3: Can CP471-51 be used together with CP461 modules?
A3: CP471-51 and CP461 cannot be mixed in a redundant setup, but complete replacement from CP461 to CP471 is supported.
Q4: What are the software requirements for CP471-51 replacement?
A4: The control station must run CENTUM VP R6.05 or later, and the bus coupler module must be EC401 style S3 or later.
Q5: What are the dimensions and weight of the CP471-51?
A5: Dimensions are 199.5 x 149 x 32.8 mm; weight is 0.7 kg.
Q6: What explosion protection options are available for CP471-51?
A6: CP471-51 is available in non-explosion proof (-0) and explosion proof (-1) versions. Refer to technical documents for details.
Q7: What accessories are included as standard?
A7: A Processor Module Modification History Label (T9044AR) is included as standard.
Q8: Is professional service required to replace CP471-51?
A8: Online replacement can be performed by the user, but upgrading from CP461 to CP471 must be carried out by a Yokogawa authorized engineer.
