Technical Specifications
| Parameter | Description |
|---|---|
| Model | EC401-10 S2 |
| Function | ESB Bus communication interface |
| Interface Type | 1 port (for N-IO/FIO) |
| Max Connectable Units | Up to 9 units (ANB10S, ANB10D, ANT401, ANT411, ANT421) |
| Transmission Speed | 128 Mbps (I/O module data transmission) |
| Max Transmission Range | 10 meters |
| Slot Installation Req. | Slot 7 (non-redundant); Slot 7 and 8 (dual-redundant setup) |
| Current Consumption | 0.5 A |
| Dimensions (W x H x D) | 130 × 129.5 × 32.8 mm |
| Weight | Approx. 0.24 kg |
| Compatible Processor | Compatible with CP471 when using EC401 Style Code S3 or later |
| SEM Support | Requires Style 2 or later for SEM usage |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many units can the EC401 module connect to?
A1: It supports connection to a maximum of 9 units (ANB10S, ANB10D, ANT401, ANT411, ANT421).
Q2: What is the maximum communication distance?
A2: The maximum transmission distance is 10 meters.
Q3: Does the EC401 support dual-redundant ESB bus configuration?
A3: Yes, dual-redundant configuration is achieved by installing two EC401 modules in slots 7 and 8.
Q4: What is the data transmission speed of the module?
A4: It supports a transmission speed of 128 Mbps for I/O data communication.
Q5: Are there specific slot requirements for installation?
A5: Yes, for non-redundant systems use slot 7; for dual-redundant, use both slot 7 and 8.
Q6: Which processor modules are compatible with EC401?
A6: EC401 modules with Style Code S3 or later are compatible with the CP471 processor module.
Q7: Does the module support Sequence of Events Manager (SEM)?
A7: Yes, but only with Style 2 or later modules.
Q8: What is the power consumption of the EC401 module?
A8: It consumes 0.5 A of current.
