Technical Specifications
| Item | Specification |
|---|---|
| Model | EC401-51 |
| Function | Interface module for connecting Field Control Unit and Node Unit via ESB bus |
| Interface Type | ESB Bus |
| Max. Connectable Units | Up to 9 units (ANB10S, ANB10D, ANT401, ANT411, ANT421) |
| Transmission Speed | 128 Mbps (for I/O module data transfer) |
| Max. Transmission Distance | 10 meters |
| Current Consumption | 0.5 A |
| Installation Slot (Single) | Slot 7; Slot 8 must be covered with a dummy module |
| Installation Slot (Redundant) | Slot 7 and Slot 8 |
| Dimensions | 130 x 129.5 x 32.8 mm |
| Weight | Approx. 0.24 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the EC401-51 module?
A1: It serves as a communication interface between the Field Control Unit and Node Unit via the ESB bus.
Q2: How many I/O units can be connected to this module?
A2: Up to 9 units including ANB10S, ANB10D, ANT401, ANT411, or ANT421.
Q3: What is the transmission speed of the module?
A3: The transmission speed is 128 Mbps, designed for high-speed I/O data communication.
Q4: How is the installation different for single and redundant channels?
A4: For single channel, install in Slot 7 and cover Slot 8 with a dummy; for redundancy, use both Slot 7 and Slot 8.
Q5: Does this module support explosion protection?
A5: Yes, models with suffix “-E” support explosion protection.
Q6: Are there any version requirements for using SEM?
A6: Yes, SEM functionality requires EC401 style 2 or later.
Q7: Can it be used with the CP471 processor module?
A7: Only EC401 style S3 or later is compatible with the CP471 processor.
Q8: Which Field Control Unit models are compatible?
A8: Compatible units include AFV30S, AFV30D, AFV40S, AFV40D, A2FV50S, A2FV50D, A2FV70S, and A2FV70D.
