Technical Specifications
| Item | Specification |
|---|---|
| Model | NFPW442-50 |
| Input Type | AC 220–240V |
| Input Voltage Range | 170–264 V AC (rms) |
| Input Frequency | 47–66 Hz (Rated: 50/60 Hz) |
| Max Input Current | 0.7 A |
| Fuse Rating | 3.15 A |
| Inrush Current | Max. 90 A (≤ 5 ms) |
| Leakage Current | Max. 1 mA |
| Dielectric Strength | 3000 V AC for 1 min |
| Insulation Resistance | ≥ 50 MΩ at 500 V DC |
| Momentary Power Failure | 2 ms (maintains ≥ 90% output) |
| Output Voltage | +5.1 V DC (rated) |
| Rated Output Current | 0–7.8 A (rated), 11.8 A (peak) |
| Total Output Power | 40 W (rated), 60 W (peak) |
| Startup Time | Max. 300 ms |
| Overvoltage Protection | Max. 7 V |
| Overcurrent Protection | ≥ 105% (shutdown in 4–14 seconds) |
| Analog Field Power Input | 24 V DC ±10% |
| Analog Field Input Current | Max. 4 A |
| Analog Field Output Voltage | Input minus diode drop |
| Analog Field Output Current | 4 A (rated) |
| Overvoltage Protection (Field) | Max. 35 V |
| Redundancy Configuration | Supported (only on NFBU200 base) |
| Dimensions (W x H x D) | 49.7 x 130 x 146.5 mm |
| Weight | 0.6 kg |
| Indicators | SYS-POWER (5V), FLD-POWER (24V), green LED |
FAQ
Frequently Asked Questions (FAQ)
Q1: What voltage range does the NFPW442-50 support?
A1: It supports AC input from 220–240V, with a range of 170–264V AC.
Q2: Can this module be used in redundant configurations?
A2: Yes, it supports redundancy when mounted on an NFBU200 base unit.
Q3: Does the NFPW442-50 provide field power output?
A3: Yes, it supplies 24V DC analog field power for I/O modules and field devices.
Q4: What is the peak output current?
A4: Peak current is 11.8 A, with a rated current of 0–7.8 A.
Q5: How long does it take to stabilize after power-on?
A5: The maximum startup time is 300 milliseconds.
Q6: What triggers overcurrent protection?
A6: If output current exceeds 105%, the module shuts down after 4–14 seconds.
Q7: What are the module’s dimensions?
A7: The dimensions are 49.7 mm (W) x 130 mm (H) x 146.5 mm (D).
Q8: Are there restrictions on where this module can be installed?
A8: Yes, it can only be installed on an NFBU200 base and requires appropriate slot placement.
