Technical Specifications
| Item | Details |
|---|---|
| Model | SAI143-S53 |
| Number of Input Channels | 16 channels, module isolation |
| Rated Input Range | 4 to 20 mA |
| Permissible Input Range | 0 to 25 mA |
| Input Impedance (ON) | 250 Ω + current value (due to internal protection drop) |
| Input Impedance (OFF) | Minimum 500 kΩ |
| Rated Accuracy | ±16 µA (Input range: 1 to 23 mA) |
| Data Update Frequency | 40 ms |
| Temperature Drift | ±16 µA per 10°C |
| Transmitter Power Supply | Min 16.15 V (20 mA), Max 26.4 V (0 mA), Limit 25 mA |
| 2/4-wire Setting | Individually set per channel using setting pins |
| Withstand Voltage | 1.5 kV AC between input and system for 1 minute (500 V AC with dedicated cable) |
| Max Current Consumption | 320 mA (5 V), 550 mA (24 V) |
| External Connections | Pressure clamp, MIL cable, or dedicated signal cable |
| HART Support | Not supported in SAI143-S53 |
| Dimensions | 130 × 107.5 × 32.8 mm |
| Weight | Approx. 0.34 kg (without signal cable adapter) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of input signal does the module support?
A1: It supports 4 to 20 mA current input signals.
Q2: Does this module support HART communication?
A2: No, the SAI143-S53 does not support HART. Use the SAI143-H model for HART support.
Q3: Is channel isolation provided?
A3: Yes, the module provides module-level isolation for all channels.
Q4: What is the power consumption of the module?
A4: It consumes 320 mA at 5 V and 550 mA at 24 V.
Q5: What is the withstand voltage of the module?
A5: 1.5 kV AC for 1 minute between input and system (or 500 V AC with a dedicated cable).
Q6: Can each channel be configured as 2-wire or 4-wire?
A6: Yes, each channel can be individually configured via setting pins.
Q7: What is the accuracy of input measurement?
A7: ±16 µA within the input range of 1 to 23 mA.
Q8: What is the module’s weight?
A8: The module weighs approximately 0.34 kg in standard configuration.
