Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SAI533-H53 |
| Number of Channels | 8 channels, module isolated |
| Rated Output Range | 4 to 20 mA |
| Guaranteed Precision Range | 1.25 to 23 mA |
| Output Range | 1.25 to 23 mA |
| Load Resistance Range | 230 to 600 Ω (at rated range) |
| Accuracy | ±48 µA |
| Data Update Frequency | 40 ms |
| Temperature Drift | ±16 µA/10°C |
| Withstand Voltage | 1.5 kV AC between output and system (1 min) |
| Max Current Consumption | 5V: 320 mA, 24V: 300 mA |
| External Connection | Pressure clamp terminal, MIL cable, signal cable |
| Supported Functions | HART communication, PST (Partial Stroke Test) |
| Dimensions (W×H×D) | 130 × 124 × 32.8 mm |
| Weight | 0.33 kg (with signal cable interface adapter) |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many output channels does the SAI533-H53 have?
A1: It provides 8 analog output channels with channel-to-channel isolation.
Q2: What is the supported current output range?
A2: The rated output range is 4 to 20 mA, with guaranteed precision from 1.25 to 23 mA.
Q3: What is the allowable load resistance range?
A3: It supports 230 to 600 ohms at the rated output current range.
Q4: Does the module support HART communication?
A4: Yes, it supports HART protocol and allows connection of one HART device per channel, including PST functionality.
Q5: What is the data update frequency?
A5: It updates output data every 40 milliseconds.
Q6: What is the operating temperature range?
A6: It operates reliably from -20°C to +70°C.
Q7: What is the output accuracy of the module?
A7: The accuracy is ±48 µA, with a temperature drift of ±16 µA per 10°C.
Q8: What are the module’s dimensions and weight?
A8: Its dimensions are 130 × 124 × 32.8 mm and it weighs approximately 0.33 kg.
