Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SAV144-S63 |
| Input Channels | 16 channels, module isolation |
| Rated Input Range | 1 to 5 V / 1 to 10 V |
| Permissible Input Range | ±30 V |
| Input Impedance (Power-ON) | 1 MΩ |
| Input Impedance (Power-OFF) | 100 kΩ |
| Rated Accuracy | 1 to 5 V: ±4 mV; 1 to 10 V: ±9 mV |
| Temperature Drift | 1 to 5 V: ±4 mV/10 °C; 1 to 10 V: ±9 mV/10 °C |
| Data Update Frequency | 40 ms |
| Withstand Voltage | 1.5 kV AC for 1 min (input signal to system) |
| Max. Current Consumption | 5 V: 300 mA; 24 V: 140 mA |
| External Connections | Pressure clamp terminal / MIL cable / Dedicated signal cable |
| Dimensions (W x H x D) | 130 × 124 × 32.8 mm |
| Weight | 0.29 kg (with signal cable interface adapter) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What input voltage ranges does the SAV144-S63 support?
A1: It supports 1–5 V and 1–10 V voltage input ranges.
Q2: How many input channels are available on this module?
A2: It provides 16 isolated input channels.
Q3: What is the accuracy of voltage measurement for each range?
A3: ±4 mV for 1–5 V and ±9 mV for 1–10 V.
Q4: Is the module isolated from the system?
A4: Yes, the input channels are module isolated.
Q5: Can this module tolerate input beyond its rated voltage?
A5: Yes, it can accept up to ±30 V without damage.
Q6: What is the data update cycle?
A6: The update frequency is 40 milliseconds.
Q7: What type of wiring or connectors can be used?
A7: It supports pressure clamp terminals, MIL cables, and dedicated signal cables.
Q8: What are the dimensions and weight of this module?
A8: The module measures 130 x 124 x 32.8 mm and weighs approximately 0.29 kg.
