Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SB401-11 S1 |
| Module Type | ESB Bus Interface Slave Module |
| Bus Type | ESB (Extension System Bus) |
| Function | Data communication between I/O modules and FCU |
| Power Supply Configuration | Supports dual-redundant operation |
| Mounting | 19-inch rack mounting |
| Compatible Node Units | ANB10S, ANB10D |
| Applicable Systems | CENTUM VP, N-IO / FIO |
| Number of Modules per Node | Max. 2 SB401 modules (for redundancy) |
| Operating Voltage | Supplied via power module (PW481/482/484) |
| External Dimensions (mm) | 130 x 142.5 x 32.8 |
| Weight | Approx. 0.45 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the SB401-11 S1 module?
A1: It acts as an interface between field I/O modules and the Field Control Unit (FCU) via the ESB bus.
Q2: How many SB401 modules can be used in one node unit?
A2: A maximum of two SB401 modules can be installed per node unit to support dual-redundant communication.
Q3: What types of systems is this module compatible with?
A3: It is designed for Yokogawa CENTUM VP systems and supports both N-IO and FIO configurations.
Q4: Does the SB401 support redundancy?
A4: Yes, the module supports dual-redundant configurations when two SB401 modules are used.
Q5: Can this module be mounted independently of a node unit?
A5: No, it must be installed inside a node unit such as ANB10S or ANB10D.
Q6: What power source does the SB401 rely on?
A6: Power is supplied through the node unit’s power supply module (PW481, PW482, or PW484).
Q7: What is the physical size of the SB401-11 S1 module?
A7: It measures 130 mm x 142.5 mm x 32.8 mm.
Q8: What is the weight of the SB401 module?
A8: The module weighs approximately 0.45 kg.
