Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | SB401-50 S1 |
| Product Type | ESB Bus Interface Slave Module |
| Function | Interfaces with FCU for I/O communication |
| Bus Type | ESB Bus |
| Configuration Support | Dual-redundant supported (2 modules max) |
| Compatible Node Units | ANB10S / ANB10D |
| Power Supply | Supplied via Power Module (PW481/PW482/PW484) |
| Max Number of I/O Modules | 8 per node unit |
| Mounting Type | 19-inch rack mounting (M5 x 4 screws) |
| Operating Voltage | Via ANB node unit (AC 100–120 V / 220–240 V / 24 V DC) |
| Power Consumption | Follows ANB node specification |
| Dimensions (W x H x D) | 130 x 142.5 x 32.8 mm |
| Weight | 0.45 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the SB401-50 S1 module?
A1: It serves as a slave module to interface analog and digital I/O signals between the FCU and field devices via the ESB bus.
Q2: Can SB401-50 S1 be used in redundant configurations?
A2: Yes, two SB401 modules can be installed in dual-redundant configurations within the ANB10D node unit.
Q3: How many SB401 modules are used per node unit?
A3: One SB401 module is used for single configuration, and two are used for dual-redundant configurations.
Q4: Which power modules are compatible with the SB401 module?
A4: It is compatible with PW481, PW482, and PW484 power supply modules.
Q5: Is the SB401 compatible with both ANB10S and ANB10D node units?
A5: Yes, it can be used in both single (ANB10S) and dual-redundant (ANB10D) configurations.
Q6: What is the recommended installation method for SB401?
A6: It should be mounted in a 19-inch rack using four M5 screws.
Q7: Are there any environmental options for SB401 usage?
A7: Yes, options are available with ISA G3 environmental rating and explosion protection (depending on node configuration).
Q8: What is the maximum number of I/O modules that SB401 can support in a node unit?
A8: Each node unit using SB401 can support up to 8 I/O modules.
