Technical Specifications
| Parameter | Description |
|---|---|
| Model | SDV521-S63 |
| Number of Outputs | 4 channels, module isolation |
| Output Voltage | 24 V DC |
| Output Voltage Drop | Max 1 V |
| External Power Rating | 24 V DC, minimum 10 A |
| External Power Capacity | 8.2 A |
| Max Leak Current (Off) | 1.6 mA |
| Output Format | Current source |
| Max Load Current/Ch | 2 A (8 A total) |
| Min Load Current | 100 mA |
| Load Resistance Range | 12 to 240 Ω |
| Max Lamp Load | 1 A per output channel |
| Output Response Time | Max 30 ms |
| Withstand Voltage | 2 kV AC between output lines and system |
| Power Consumption | Max 280 mA (5 V DC), 140 mA (24 V DC) |
| Dimensions (W x H x D) | 130 x 32.8 x 125.5 mm |
| Weight | 0.36 kg |
| External Connection | Dedicated signal cable AKB651 |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum load current per channel?
A1: Each channel supports up to 2 A, with a total output limit of 8 A.
Q2: Can the module drive filament lamps?
A2: Yes, each output supports up to 1 A for lamp loads and can tolerate inrush currents up to 10 times.
Q3: What is the output voltage?
A3: The module provides 24 V DC output with a voltage drop not exceeding 1 V.
Q4: What is the minimum required load current?
A4: The minimum load current per channel is 100 mA.
Q5: What are the physical dimensions and weight of the module?
A5: It measures 130 x 32.8 x 125.5 mm and weighs approximately 0.36 kg.
Q6: What are the power supply requirements?
A6: The external power supply must be 24 V DC (+20% / -10%) with a minimum current capacity of 8.2 A.
Q7: Is there leakage current when the output is off?
A7: Yes, the maximum leakage current is 1.6 mA.
Q8: Does the module offer channel isolation?
A8: Yes, the SDV521-S63 provides full channel-to-channel and channel-to-system isolation.
